RDL Series
LED Round Flush Mount
RDL Series LED disk light provides versatile lighting on standard line voltage, yet produces the high energy savings you desire from LED fixtures. The RDL series allows for easy upgrade your down lighting from the traditional recessed cans to a more modern looking, energy efficient solution. Energy Star Rated for 5", 7" and 12" versions. This disk light can be easily mounted onto a junction box or can be retrofitted into an existing recessed can with the optional hardware mounting adapter (not included).
Resources
Photometry
- High-transmission (White) Acrylic lens with excellent distribution and uniformity.
- Full distribution LED Luminaire.
- 120V AC with Driver on Board Technology.
- Impact Resistant Acrylic Lens
- 10-100% dimming driver, compatible with most Triac dimming switches in the market
- Can be retrofit into most 5” or 6” recessed down-lights or surface mounted for new construction applications
- Designed for a 50,000 Hour Life
- Available in 3000K, 4000K or CCT Adjustable Kelvin temperatures
- Environmentally friendly – contains no mercury or other hazardous
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 90 CRI
Color / Finish
- Black
- Brushed Nickel
- White
Dimensions
- H: 0.7 In. L: 5.4 In. W: 5.4 In.
- H: 0.7 In. L: 7.9 In. W: 7.9 In.
- H: 0.7 In. L: 9 In. W: 9 In.
- H: 0.7 In. L: 12 In. W: 12 In.
Dimming Protocol
- Triac
Efficacy
- 55 lm/w
- 63.3 lm/w
- 65 lm/w
- 70 lm/w
Installation Type
- New Construction
- Retrofit & Remodel
Lamp Base
- Integrated
Lamp Life
- 30000 hrs
Lamp Source
- LED
Listings
- ETL
Lumens
- 550 Lm
- 950 Lm
- 1170 Lm
- 1540 Lm
Materials
- Metal
- Plastic
Ratings & Compliance
- Energy Star
- JA8
- LM80
- RoHS
- Title 24
Shape
- Round
Trim Type
- Downlight
Voltage
- 120 V
- 277 V
Warranty
- 3 yr
Watts
- 10 w
- 15 w
- 18 w
- 22 w
