MDL Series

LED Disk Light

The MDL Series LED disk light provides versatile lighting on standard line voltage, yet produces the high energy savings you desire from LED fixtures. The MDL series allows for easy upgrade your downlighting from the traditional recessed cans to a more modern looking, energy efficient solution. This disk light can be easily mounted onto a junction box or can be retrofitted into an existing recessed can with the optional hardware mounting adapter. Ideal for closets, storage areas, attics, corridors, or as general lighting solution for residential and commercial applications.
Specification Sheet

Resources

Specsheets


  • Die Cast Aluminum housing with diffusion lens for optimal visual comfort while providing uniform light output.
  • Lens design and materials provide uniform appearance without pixelation.
  • Equipped standard with 120V 15-100% dimming driver.
  • All luminaires are built to UL 1598 and 2108 standards, and bear appropriate ETL labels.
  • Wet location labeling is standard.
  • Adheres to LM70, LM80, and TM21 industry standards.
  • Dedicated 120V Models are FCC Title 47 CFR, Part 15, Class B for residential and commercial applications.

CCT

  • 3000K
  • 4000K

CRI

  • 80 CRI

Color / Finish

  • Brushed Nickel
  • White

Efficacy

  • 66 lm/w

Lamp Base

  • Integrated

Lamp Life

  • 50000 hrs
  • 72000 hrs

Lamp Source

  • LED

Listings

  • ETL

Lumens

  • 800 Lm

Materials

  • Aluminum

Ratings & Compliance

  • Energy Star
  • FCC
  • LM80
  • TM21
  • Wet

Shape

  • Round

Voltage

  • 120 V

Warranty

  • 3 yr

Watts

  • 12 w
