HEF Series

52"Ceiling Fan

The HEF series are a family of ceiling fans featuring a simple 5 blade design. The clean lines and traditional design of this AC Motor LED fan makes an elegant addition to your home décor. The reversible feature makes this fan perfect to use during every season.
Specification Sheet

Resources

  • The HEF series are a family of ceiling fans featuring a simple 5 blade design.
  • Steel Housing, Plywood Blades and Frosted Glass Light Diffuser provides uniform appearance without pixelation.
  • 3-Speed AC Motor with 80″ Lead Wire. Includes (1) 5″ Downrod.
  • 52″ Sweep, 5 Blade Configuration Blade Pitch Angle:12°.
  • Operates at 120V 60HZ.
  • All ceiling fans are built to UL 507 standards, and bear appropriate ETL labels. Dry location labeling is standard.

Blade Count

  • 5

Blade Pitch

  • 12º

Blade Span

  • 52 In.

CCT

  • 3000K
  • 4000K
  • 5000K

CRI

  • 80 CRI
  • 81 CRI

Color / Finish

  • Black
  • Brushed Nickel
  • White

Dimming Protocol

  • Triac

Listings

  • ETL

Materials

  • Glass
  • Steel

Ratings & Compliance

  • Dry
  • LM80

Voltage

  • 120 V

Warranty

  • 3 yr

Watts

  • 01 w
  • 5 w
  • 8 w
  • 18 w
  • 19 w
  • 82 w
  • 100 w
