SWL Series
_0094_SWL-WH-10.pngSWL Series
CCT Adjustable LED Stairwell Fixture
The SWL Series of LED stairwell fixtures are a cost effective, energy-saving replacement for less efficient fluorescent fixtures. The SWL fixture features 120° light angle covered with an polycarbonate lens and a one-piece fabricated steel body. These LED stairwell fixtures are ideal for lighting in parking garages and stairwells and/or other applicable building lighting in residential multi-family buildings, workshops, utility rooms, corridors and other commercial applications.
Resources
- CCT Adjustable Switch provides optional kelvin temperatures 3000/3500/4000K
- Rugged construction, solid die formed, cold rolled steel housing
- Optional sensors available
- Long life rating at 50,000 hours
- 5 year warranty
Beam Angle
- 120
CCT
- Field Selectable CCT
- 3000K
- 3500K
- 4000K
CRI
- 80 CRI
Color / Finish
- White
Controls Options
- Motion Sensor
Dimensions
- H: 3.1 In. L: 24 In. W: 4.2 In.
- H: 3.1 In. L: 48 In. W: 4.2 In.
Dimming Protocol
- 0-10 V
Efficacy
- 90 lm/w
Lamp Life
- 50000 hrs
Lamp Source
- LED
Listings
- ETL
Lumens
- 1530 Lm
- 3060 Lm
Materials
- Aluminum
- Polycarbonate
- Steel
Mounting
- Ceiling
- Surface
- Wall
Ratings & Compliance
- Damp
- LM80
- TM21
Voltage
- 120-277 V
Warranty
- 5 yr
Watts
- 17 w
- 34 w
