OCMS Series

Outdoor Cylinder With Motion Sensor

The OCMS Series is a family of LED Outdoor Cylinders. The OCMS mounts to a wall, creating an inviting exterior space as well as providing safety and security. Made of sturdy die cast aluminum housing featuring a tempered glass lens. Ideal for use in hallways, garages, patios, and porches. Equipped with an On/Off PIR sensor.
Specification Sheet

Resources

  • Rugged die cast aluminum housing withstands outdoor environments.
  • Outer surface treated with durable power coating to provide resistant to corrosion, rust, weathering, and or degradation.
  • Performance engineered internal heat dissipation fins provide superior thermal management for LED life and reliability.
  • Clear Tempered glass lens.
  • Equipped standard with fixed output 120V driver operating at 60Hz. Long Life LED’s, 60,000 hours at L80 with projected life over 100,000 hours for reduced life cycle maintenance costs.
  • 3000K LED color (Kelvin) temperature and > 80 CRI.
  • All luminaires are built to UL 1598 and 2108 standards, and bear appropriate ETL labels.

CCT

  • 3000K

CRI

  • 80 CRI

Color / Finish

  • Black

Controls Options

  • Motion Sensor
  • Photocell

Efficacy

  • 70 lm/w

Lamp Base

  • Integrated

Lamp Life

  • 60000 hrs
  • 72000 hrs
  • 100000 hrs

Lamp Source

  • LED

Listings

  • ETL

Lumens

  • 840 Lm

Materials

  • Aluminum
  • Glass

Ratings & Compliance

  • Exterior
  • FCC
  • LM80
  • TM21
  • Wet

Shape

  • Cylinder

Voltage

  • 120 V

Warranty

  • 3 yr

Watts

  • 12 w
